Group | Formation | Member | Type well | Interval | Location | Reference well | Interval | Location | |
Paleogene | Hordaland | Lark | UK 21/10-4 | 1217-1867 m | |||||
Skade | 24/12-1 | 1007-851 m | N 59°02'29.80 E 01°52'57.93 | 15/9-13 | 1224-1143 m | N 58°22'25.96 E 01°56'02.86 | |||
Vade | 2/2-1 | 2172-2100 m | 2/3-2 | 1855-1795 m | |||||
Horda | UK22/1-1A | 1992-2379.5 m | UK9/4-1 | 1026.5-1835 m | |||||
UK16/18-1 | 1852.5-2356.5 m | ||||||||
UK21/22-1 | 1076-1234.5 m | ||||||||
Grid | 15/3-3 | 1840-1470m | 24/12-1 | 1660-1502 m | |||||
24/12-2 | 1397-1282 m | ||||||||
Frigg | 25/1-1 | 2115-1836 m | 30/7-6 | 1923-1783 m | |||||
Rogaland | Balder | 25/11-1 | 1780-1705 m | N 59°10'57.39, E 02°24'28.18 | 30/2-1 | 1993-1917 m | N 60°52'05.42, E 02°38I49.16 | ||
15/9-17 | 2253-2204 m | N58°26'44.19, E 0l°56'53.58 | |||||||
Odin | UK 9/18a-15 | 1875-1676 m | N 59°26'36.67" E 01°33'20.08" | 25/7-17 | 1647-1587 m | N 59°03'26.66" E 02°29'06.59" | |||
Radøy | 35/8-3 | 1525-1418 m | N 61°21'05.35", E 03°32'02.63" | 35/8-1 | 1685-1675 m | N 61°21'26.37", E 03°21'44.09" | |||
Sele | UK21/10-1 | 2131-2100 m | N 57°43'50.37, E 00°58'29.19 | 31/2-6 | 1225-1167 m | N60°54 13.57, E 03°38'49.43 | |||
Forties | UK21/10-1 | 2370-2131 m | N 57°43'50.37, E 00°58'29.19 | 7/11-1 | 3069-2904 m | N 57°04'15.60, E 02°26'24.40 | |||
Hermod | 25/2-6 | 2361-2221 m | N 59°45'33.55, E 02°33'05.96 | UK10/1-1 | 2212-2127 m | N 50°50'10.50, E 02°00'33.60 | |||
Fiskebank | 9/11-1 | 1483-1335 m | N 57°00'41.40, E 04°500'33.52 | 8/9-1 | 1375-1315 m | N 57°26'27.28, E 03°51'03.48 | |||
Solund | |||||||||
Unresolved Sele/Lista | Vidar | 2/1-4 ? | 3138-3075 m | N 56°54'39.82, E 03°04'02.25 | 1/3-1 ? | 3147-3095 m | N 56°51'21.00, E 02°51'05.00 | ||
Lista | 2/7-1 | 2918-2873 m | N 56°25'44.68, E 03°12'14.21 | 15/9-11 | 2386-2308 m | N 58°24'02.53, E 01°53'41.79 | |||
16/8-1 | 1749-1708 m | N 58°27'24.80, E 02°25'56.80 | |||||||
Mey | UK 21/2-1 | 2356.5-2002.5 m | N 57°55'14.490", E 00°15'46930" | 7/11-2 | 3107-3027 m | N 57°43'50.37, E 00°58'29.19 | |||
Heimdal | 25/4-1 | 2423-2067 m | N 59°34'27.30, E 02°13'22.60 | 15/9-11 | 2423-2385 m | N 58°24'02.53", E 01°53'41.79" | |||
Sotra | 35/8-3 | 1709-1665 m | N 61°21'05.35", E 03°32'02.63" | 35/3-1 | 1422-1392 m | N 61°50'41.89", E 03°43'41.36" | |||
Siri | DK Siri-2 | 2205.5-2127 m | N 56°29'40.53", E 04°52'13.26" | DK Connie-1 | 2368.3-2292.2 m | N 56°24'28,34", E 04°42'30,36" | |||
Våle | 1/3-1 | 3258-3209 m | N 56°51'21.00, E 02°51'05.00 | 15/9-5 | 2774-2736 m | N 58°24'12.47, E 01°42'29.20 | |||
2/7-1 | 2934-2918 m | N 58°25'44.68, E 03°12'14.21 | |||||||
Borr | DK Augusta-1 | 2963.2-2940.5 m | N 56°17'57.40", E 04°24'04.64" | 3/7-4 | 2845-2815 m | N 56°24'15.60", E 04°14'22.24" | |||
Ty | UK10/1-1 | 2767-2421 m | N 59°50'10.50'', E 02°00'33.60'' | 15/3-1 | 2715-2556m | N58°50'57.00'', E 01°43'13.25 | |||
Maureen | 7/11-1 | 3173-3069 m | N 57°04'15.60", E 02°26'24.40" | 15/12-1 | 2644-2616 m | N 58°10'32.60", E 1°44'23.10" | |||
Våle/Tang | Egga | 6305/5-1 | 2770.4-2718 m | N 63°32'27.50", E 5°20'14.90" | 6205/3-1 | 1482-1317 m | N 62°57'08.62", E 5°56'38.11" | ||
Chalk | Ekofisk | 2/4-5 | 3164-3037 m | N 56°34'29.77, E 03°12'13.03 | 1/3-1 | 3354-3258 m | N 56°51'21.00, E 02°51'05.00 | ||
UK22/1-2A | 2982.5-2935 m | N 57°56'12.20, E 01°02'55.80 | |||||||
2/5-1 | 3132-3041 m | N 56°38'19.95, E 03°21'07.94 |
