Lithostratigraphy (Norwegian Sea) | Maps of Norwegian Sea | Table of Well Locations
 |
 |
| Group | Formation | Member | Type well | Interval | Location | Reference well | Interval | Location | |
| Cretaceous | Shetland (redefined in Norwegian Sea) | 6506/12-1 | 3705-2279 m | N 65°10'07.58 E 06°43'44.07 | |||||
| Springar | 6506/12-4 | 2380-2211 m | N 65°12'46.97 E 06°43'30.37 | 6506/12-1 | 2446-2279 m | N 65°10'07.58 E 06°43'44.07 | |||
| Hvithval (new) | 6704/12-1 | 3244-2552.7 m | N 67°07'25.00 E 04°42'44.70 | 6707/10-1 | 2434-2213 m | N 67°04'07.85 E 07°00'36.51 | |||
| Grindhval (new) | 6305/5-1 | 2813.5-2779 m | N 63°32'27.50 E 5°20'14.90 | 6305/8-1 | 3005-2976 m | N 63°28'34.70 E 5°24'14.40 | |||
| Nise | 6506/12-4 | 2600-2380 m | N 65°12'46.97 E 06°43'30.37 | 6506/12-1 | 2658-2446 m | N 65°10'07.58 E 06°43'44.07 | |||
| Spekkhogger (new) | 6707/10-1 | 3810-2977 m | N 67°04'07.85 E 07°00'36.51 | 6704/12-1 | 3968-3646.5m | N 67°07'25.00 E 04°42'44.70 | |||
| Nebbhval (new) | 6610/3-1 | 2306-2282 m | N 66°55'29.70E 10°54'06.28 | ||||||
| Kvitnos | 6506/12-4 | 3132.5-2600 m | N 65°12'46.97 E 06°43'30.37 | 6506/12-1 | 3175-2658 m | N 65°10'07.58 E 06°43'44.07 | |||
| Tumler (new) | 6707/10-1 | 4241-3939 m | N 67°04'07.85 E 07°00'36.51 | 6706/11-1 | 3465-3101 m | N 67°04'24.77 E 06°27'47.70 | |||
| Kvitskjæving (new) | 6610/3-1 | 2543-2504.5m | N 66°55'29.70 E 10°54'06.28 | ||||||
| Blålange (new) | 6506/12-1 | 3705-3175 m | N 65°10'07.58 E 06°43'44.07 | 6610/3-1R | 3412-2655 m | N 66°55'29.70 E 10°54'06.28 | |||
| 6506/12-4 | 3755.5-3132.5 m | N 65°12'46.97 E 06°43'30.37 | |||||||
| Lysing (redefined) | 6507/7-1 | 3000-2926 m | N 65°27'16.7 E 07°12'52.6 | 6506/12-4 | 3150-3132.5 m | N 65°12'46.97 E 06°43'30.37 | |||
| 6506/11-3 | 3202-3121 m | N 65°13'58.44 E 06°22'26.89 | |||||||
| 6506/3-1 | 3110.5-3090 m | N 65°48'20.75 E 06°44'32.64 | |||||||
| Tunge (new) | 6306/10-1 | 1858-1825 m | N 63°09'26.32 E 06°19'41.45 | 6305/12-1 | 2642-2616 m | N 63°01'25.73 E 05°47'23.94 | |||
| Skrubbe (new) | 6610/3-1R | 3047-2884 m | N 66°55'29.70 E 10°54'06.28 | ||||||
| Skolest (new) | 6306/10-1 | 1999-1992 m | N 63°09'26.32 E 06°19'41.45 | 6305/1-1 | 4529-4504 m | N 63°46'59.72 E 05°16'19.57 | |||
| Breiflabb (new) | 6507/2-2 | 3293-3263 m | N 65°55'01.69 E 07°30'54.56 | 6507/7-1 | 3523-3495.5 m | N 65°27'16.7 E 07°12'52.6 | |||
| Smørflyndre (new) | 6507/2-2 | 3334.5-3330 m | N 65°55'01.69 E 07°30'54.56 | 6506/11-4S | 4321-4236 m | N 65°01'46.17 E 06°36'04.74 | |||
| Sandflyndre (new) | 6610/3-1R | 3412-3201 m | N 66°55'29.70 E 10°54'06.28 | ||||||
| Gapeflyndre (new) | 6305/12-1 | 3451.5-3230 m | N 63°01'25.73 E 05°47'23.94 | ||||||
| Cromer Knoll (redefined in Norwegian Sea) | 6506/12-1 | 3836-3705 m. Note base amended from 3835 m by Dalland et al. 1988 (in addendum) | N 65°10'07.58 E 06°43'44.07 | ||||||
| Langebarn | 6506/12-1 | 3812.5-3705 m | N 65°10'07.58 E 06°43'44.07 | 6506/12-4 | 3835-3755.5 m | N 65°12'46.97 E 06°43'30.37 | |||
| Lyr | 6506/12-1 | 3836-3812.5 m Note base amended from 3835 m by Dalland et al. 1988 (in addendum) | N 65°10'07.58 E 06°43'44.07 | 6407/1-2 | 3526-3510 m | N 64°47'50.61 E 07°02'23.76 |
